OPERATION

MACHINE MAINTENANCE

To keep machine in good working condition, simply
follow the daily, weekly and monthly maintenance
procedures.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
WARNING: Disconnect Battery Cables Before
Servicing Machine.
ATTENTION: Contact an Authorized Service
Center for machine repairs. Machine repairs
performed by other than an authorized person will
void your warranty.

DAILY MAINTENANCE

(Every 4 Hours of Operation)
1. Drain and rinse tanks thoroughly (Figure 33). After
draining tanks, hinge recovery tank until you can
see vacuum intake hole at rear of tank. Remove
any debris in hole if necessary.
FIG. 33
2. Remove and rinse off the float shut--off screen
located in recovery tank (Figure 34).
FIG. 34
16
Home Home Find... Go To.. Find... Go To..
3. Empty and rinse out debris trough (Figure 35).
FIG. 35
4. Wipe blades down with a dry cloth and store
squeegee in the up position to prevent squeegee
damage (Figure 36). Check squeegee blades for
damage and wear. Rotate or replace blades when
worn or damaged.
FIG. 36
5. Check brushes for wear and entangled debris.
Change brushes if bristles are worn to a length of
0.38 in / 10 mm or less (Figure 37).
FIG. 37
