Customising Settings for Your Home

Main remote controller
To change the settings of your heating/cooling system, please use the main remote controller located on the wall or the front panel of the cylinder unit or hydrobox. The fol-
lowing is a guide to viewing the main settings. Should you require more information, please contact your installer or local Mitsubishi Electric dealer. Some functions are not
available depending on the system configuration. These functions are grayed out or not shown.
Note: The terms displayed on the remote controller are enclosed in square brackets.
LED*2
13
14
<Home screen icons>
No. Icons Description
Alert (for multiple outdoor units con-
trol)
Touching the menu icon displays
1
error codes.
Alert
J1
Error codes are displayed.
SD card is inserted. Normal opera-
tion
2
SD card is inserted. Abnormal opera-
tion
Heating mode
3
Cooling mode
Holiday schedule is activated.
4
Legionella prevention mode is run-
5
ning.
Smart grid ready is running.
6
Compressor is running.
Compressor is running and defrost-
ing.
Compressor is running and in quiet
7
mode.
The sound level is shown at left side
of the icon.
Emergency heating
Electric heater is running.
8
1 2 3 4 5 6
Zone Zone
°C °C
+
°C
[Home screen] (Full screen*1)
No. Icons Description
Boiler is running.
9
Buffer tank control is running.
Schedule
Prohibited
10
Cloud control
Operation
Standby
11 This unit is in standby whilst other
indoor unit(s) is in operation by prior-
ity.
Stop
12 Actual DHW tank temperature values
Actual room temperature values
[ -- °C] appears when the unit is not connected
13
to the room RC (Remote Controller) and it is
under control other than Auto Adaptation.
• The screen will turn off when the main remote controller is not operated for a while. Touching any part of the
screen turns it on again.
• From [Touch screen] in [Setting], the brightness can be adjusted.
• By selecting [Always on] for [Backlight time] from [Touch screen] in [Setting], the backlight stays lit for 30 sec-
onds and after it dims down.
*1 From [Setting], the screen can be switched to the full screen or the base screen.
The base screen does not display the operation icons and the target temperature values.
*2 From [Display] in [Setting], the LED lamp can be turned on/off.
*3 Pressing and holding the menu icon
Some functions cannot be edited when the lock menu is on.
(The icon changes to when the lock menu is on.)
*4 Auto Adaptation cannot be selected during the cooling mode.
7 8 9 [Menu]*3
DHW
°C
°C °C
No. Icons
*4
14
15
Target temperature values
16 The settable temperature differs depending on
the control logic.
for 3 seconds switches the lock menu to on/off.
10
11
12
16
15
Description
Weather compensation curve
When the operation stops: Black
During heating operation: Orange
Auto Adaptation (Target room tem-
perature)
When the operation stops: Black
During heating operation: Orange
Flow temperature (Target flow tem-
perature)
When the operation stops: Black
During heating operation: Orange
During cooling operation: Blue
DHW icon is displayed when DHW is
enabled.
When the operation stops: Black
During operation: Orange
4
