Take note of possible risks posed by the spray mater-
u
ial. Observe the markings on the container or the man-
ufacturer's information regarding the spray material,
including the instructions about using personal pro-
tective equipment. You must comply with the manufac-
turer's instructions in order to reduce the risk of fire and
of injury caused by poison, carcinogens, etc.
Keep the battery contacts and the spray system trig-
u
ger switch free from paint and other liquids. Failure to
comply could cause electric shock.
Supervise children. This will ensure that children do not
u
play with the fine spray system.
In case of damage and improper use of the battery, va-
u
pours may be emitted. The battery can set alight or ex-
plode. Ensure the area is well ventilated and seek medical
attention should you experience any adverse effects. The
vapours may irritate the respiratory system.
Do not open the battery. There is a risk of short-circuit-
u
ing.
The battery can be damaged by pointed objects such
u
as nails or screwdrivers or by force applied externally.
An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
Only use the battery with products from the manufac-
u
turer. This is the only way in which you can protect the
battery against dangerous overload.
Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture. There is a risk of explosion and
short-circuiting.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The power tool is intended for spraying all common paints:
Emulsion and latex paints (wall paints), solvent-based and
water-dilutable (recommended) lacquers, varnishes,
primers, impregnations, clear lacquers (ALLPaint), oils and
water.
The power tool is not suitable for use with caustic solutions,
wood stains, acidic coating materials, disinfectants, pesti-
cides and house paints.
Bosch Power Tools
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Spray gun
(2)
Container for spray material
(3)
Air cap
(4)
Cap nut
(5)
Trigger switch
(6)
Thumbwheel for spray material volume
(7)
Sealing ring
(8)
Suction tube
a)
(9)
Spare container
(10) Paint nozzle
(11) Nozzle needle
(12) Container seal
(13) Ventilation hole
(14) Paint channel
(15) Base unit
(16) Battery charge indicator
(17) Sliding switch for air flow
(18) Air filter cover
(19) Release buttons
(20) Air filter
a)
(21) Rechargeable battery
a) This accessory is not part of the standard scope of delivery.
Technical Data
Fine-spray system
Article number
Rated voltage
Spraying capacity
Required time for application
2
of paint on 2 m
Container capacity for spray
material
Weight
Recommended ambient tem-
perature during charging
Permitted ambient temperat-
A)
ure during operation
and
during storage
Recommended rechargeable
batteries
English | 19
UniversalSpray
18V-300
3 603 B08 1..
V=
18
ml/min
300
min
1
ml
1200
kg
1.5 (1.5 Ah)–
1.7 (6.0 Ah)
°C
0 to +35
°C
−20 to +50
PBA 18V...W-.
1 609 92A 9JV | (26.03.2024)
