For Sliding shelves: Use cable tie strips to mount the cables on to the Cable management arms in
the back of the Sliding shelf, and then attach the cable management clips onto the sliding shelf.
For Fixed Vertical shelves: use the below cable management solution to guide the cables from the
back to the front. Be sure to close the metal pins so the cables do not fall back out.
3. Place power supplies
Place power supplies correctly on trays and make sure excessive cabling is tied up properly. Lead
the power cable through cable hole, and fit it in front cable clip.
Power sockets
Power supply tray
Cable hole for charging
4. Assembling and using main cable holder
Assemble the main cable holder onto the right side from front of the Notecart Unifit. Use a Phillips
screw driver to mount the screws and washers supplied.
