Before performing any type of maintenance/service, disengage all controls
and stop the engine. Wait until all moving parts have come to a complete
stop. Disconnect spark plug wire and ground it against the engine to
prevent unintended starting. Always wear safety glasses during operation
or while performing any adjustments or repairs.
Interval
Each Use and every 5 hours
1.
2.
3.
1st 5 hours
1.
Annually or 25 hours
1.
2.
3.
Annually or 50 hours
1.
Annually
1.
2.
Before Storage
1.
† Clean more often under dusty conditions or when airborne debris is present.
Always stop engine and disconnect spark plug wire before performing any
maintenance or adjustments. Always wear safety glasses during operation
or while performing any adjustments or repairs.
General Recommendations
•
Always observe safety rules when performing any maintenance.
•
The warranty on this yard vacuum does not cover items that have been
subjected to operator abuse or negligence. To receive full value from
warranty, operator must maintain the equipment as instructed here.
•
Some adjustments will have to be made periodically to maintain your unit
properly.
•
Periodically check all fasteners and make sure these are tight.
Engine Maintenance
Consult the separate engine operator's manual for engine maintenance instructions.
Lubrication
Wheels
Place a few drops of SAE 30 oil on each shoulder screw once a season.
Nozzle Height Adjustment Levers
Lubricate nozzle height adjustment levers with light oil.
SERVICE AND MAINTENANCE
MAINTENANCE SCHEDULE
WARNING
Item
Engine oil level
Loose or missing hardware
Unit and engine.
Engine oil
Air filter
Control linkages, pivots, & wheels
Underside of deck
Engine oil
Spark plug
Air Filter
Fuel system
WARNING
Follow the maintenance schedule given below. This chart describes service
guidelines only. Use the Service Log column to keep track of completed
maintenance tasks. To locate the nearest authorized service center or to schedule
service, call the following toll free number: 1-888-331-4569.
Service
1.
Check
2.
Tighten or replace
3.
Clean
1.
Change
1.
Clean
2.
Lube with light oil
3.
Clean
1.
Change
1.
Replace
2.
Replace
1.
Run engine until it stops from lack of fuel, or
add stabilizer to a full tank of fresh fuel prior
to storage.
Locking Rod
Lubricate the lock rod and compression springs which attach to the mounting
bracket.
Nozzle/Hose Vac Lever
Lubricate the nozzle/hose vac lever on top of the nozzle once a season with light oil.
Cleaning Equipment
Clean underside of the yard vacuum once a season to prevent build-up of debris.
Follow steps below for this job:
1.
Disconnect and ground spark plug wire. Empty the fuel tank by running
engine until tank is dry.
2.
Tip the yard vacuum so that it rests on its side, keeping the muffler side
down. Hold yard vacuum firmly.
3.
Scrape and clean the underside of the deck and nozzle with a suitable tool.
Do not spray with water.
IMPORTANT: Do not use a pressure washer or garden hose to clean your unit.
These may cause damage to bearings, or the engine. The use of water will result in
shortened life and reduce serviceability.
4.
Put the yard vacuum back on its wheels on the ground.
13
