1839123
Certificate:
70055568
Project:
CLASS 4828 82 - SIGNAL APPLIANCES - Toxic Gas Detection Instruments - For Hazardous Locations -
CERTIFIED TO U.S. REQUIREMENTS
Class I, Div. 1, Groups B, C and D; Class II, Div. 1, Groups E, F and G;
Class I, Zone 1, Group IIB + H2
Type 4X
Model IDS0105, stationary, input rated 9 to 30 V dc, 9 W, output rated 4-20 mA. May be used with splash guard,
flow cell and bump test adapter. Temperature code of T6 for -40°C to + 40°C and T4 for -40°C to + 80°C.
WARNING: "The CSA certification does not cover the gas detection performance in Class II environments. The
sensor may become clogged and may not detect gas. In this event, the detector will signal a beam block fault."
APPLICABLE REQUIREMENTS
CAN/CSA-C22.2 No. 0-M91 General Requirements – Canadian Electrical Code, Part II
C22.2 No. 25-1966 Enclosures for Use in Class II, Groups E, F and G Hazardous Locations
CSA Std C22.2 No.30-M1986 Explosion-Proof Enclosures for Use in Class I Hazardous Locations
CSA Std C22.2 No.152-M1984 Combustible Gas Detection Instruments
UL50, Eleventh Edition, Enclosures for Electrical Equipment
UL 1203 (4th Ed.) Explosion-Proof and Dust-Ignition-Proof Electrical Equipment for Use in
Hazardous (Classified) Locations
IEC E60079-0:04 Electrical apparatus for explosive gas atmospheres - Part 0: General
Requirements
IEC E60079-1:05 Electrical apparatus for explosive gas atmospheres - Part 1: Flameproof
Enclosures "d"
CENELEC EN 60079-0:06 Electrical apparatus for explosive gas atmospheres - Part 0: General
Requirements
CENELEC EN60079-1:04 Electrical apparatus for explosive gas atmospheres - Part 1: Flameproof
Enclosures "d"
ISA-12-13.01-2003 Performance Requirements for Combustible Gas Detectors
CAN/CSA-C22.2 No. Safety Requirements for Electrical Equipment for Measurement, Control,
61010-1-12 and Laboratory Use, Part 1: General Requirements
ANSI/ISA-61010-1 Safety Requirements for Electrical Equipment for Measurement, Control and
3rd Edition Laboratory Use - Part 1: General Requirements - Third Edition
DQD 507 Rev. 2012-05-22 Page 2
Master Contract: 160220
Date Issued: 2016-09-19
Supplement to Certificate of Compliance
1839123 (097594_0_000)
Certificate:
The products listed, including the latest revision described below,
are eligible to be marked in accordance with the referenced Certificate.
Product Certification History
Project Date Description
70055568 2016-09-19 Updating the report 1839123 to replace Std. C22.2 No 142-M1987, UL Std.
No 508 by CAN/CSA-C22.2 NO. 61010-1-12 Ed 3rd,ANSI/ISA-61010-1 3rd
Edition, and update some drawings
2495408 2012-12-28 Update to report 1839123 to performance test Models IDS 0101 and IDS
0102 to ISA Std. 12.13.01-2003.
1839123 2007-08-24 Stationary Gas Detectors Models IDS 0101, IDS 0102 and IDS 0105
DQD 507 Rev. 2012-05-22 Page 1
Master Contract: 160220
