Technical Data BDC2002

Model
speed Range
leD Display Accuracy
Maximum Torque
Input to Power supply
electrical Output from
Power supply to stirrer
Mechanical Output Power
Weight
Maximum Volume
Maximum Viscosity
Molded Front housing
Cast Back housing
Combined housing
Key Pad
stirlight™
Power Cord lengths
Adjustable Chuck
Technical specifications subject to change without notice
stirrer
Power supply
BDC2002
40 - 2000 rpm
± 1 rpm or 3% of reading, 4 digit
70 n-cm, (100 in-oz)
AC 100-240 volts, 50/60 hz, 125-175 VA
(Must use Caframo supplied power supply)
DC 24 V, 2 .7 A
1/15 hp, 50 watts, (Brushless DC Motor)
3 .0 kg (7 lbs)
0 .5 kg (1 lb)
25 litres (6 .6 Us gallons, 5 .3 Imp gallons)
15000 mPa .s (15000 cps) - e .g . sour cream
Flame retardant, chemical resistant, high impact
nylon . Recyclable (PA) .
epoxy coated zinc
splash Proof
Waterproof, chemical resistant polyester
5 Ultra Bright leDs, 100,000 hour life
183 cm (6') from stirrer to Power supply-DC
183 cm (6') from Power supply to wall-AC
Fits onto 13mm (33/64 inch) Ø output shaft
of stirrer . Adjusts up to 9 .5 mm (3/8 inch) .
