How to refill the spool
Should you prefer to refill the spool by yourself:
Only use a nylon line with a 1.8 mm

diameter.
Nylon lines in a diameter other than the

specified may damage the motor and the
automatic advancing system.
Remove the spool and the rest of the nylon

line.
Take one end of the wire and pass it through

hole (1) as shown in the picture.
Wind the wire in the direction indicated

by the arrow on the spool as uniformly
as possible. Follow the maximum length
recommended for the equipment is 8 meters.
Advance and automatic cutting of the
nylon line
4. With the equipment running:
Slightly press the spool against the ground.

The nylon line will automatically be released.
The cutting blade fixed to the protection
device will limit the amount of wire released.
Press the spool against the ground as many

times as necessary.
In order not to damage the equipment or the

protection device, only press the metal part
of the spool (1) against the ground.
32
1
1
1
5. You may want to carry out this operation
manually:
Unplug the equipment.

Press the metal part of the spool (1) with

one hand and with the other pull the nylon
line (2) in the necessary length. If the wire
exceeds the ideal length, it will be cut by the
blade fixed to the protection device.
2
2
2
Fixing the extension cord to the
equipment
There is a locking system in the lower part of
the handle to facilitate usage and to prevent the
extension cord from being disconnected from the
wall outlet. To use this system, do as shown in
the next figure:
Put the extension cord in hole (1).

Pass the cord over the lock (2).

Connect the equipment plug to the extension

cord (3).
