2. Connect the I/O Module cable's DB15 connector to the I/O module's I/O
connector.

Connect the Ethernet Cable

The I/O module's PoE port provides power and Ethernet connectivity to the In-Sight
Micro vision system.
CAUTION:
All cable connectors are "keyed" to fit the connectors on the vision
l
system; do not force the connections or damage may occur.
Connecting third-party devices to the I/O module's PoE port could
l
damage the I/O module.
1. Connect the Ethernet cable's M12 connector to the vision system's PoE
connector.
2. Connect the Ethernet cable's RJ-45 connector to the I/O module's PoE port.
3. Restore power to the I/O module's 24VDC power supply and turn it on if
necessary.
4. Use In-Sight Explorer software to configure the vision system and I/O
module. For more information, refer to the In-Sight
which is available from the Help menu or by pressing the F1 key.
®
11
Explorer Help file,
