Precautions for installation
Be sure to ask the dealer for the installation, adjustment and connection of this equipment.
Flat washers for use with 1/4˝ screws: 2 (For mounting the camera) or
Flat washers for use with 3/8˝ screws: 2 (For mounting the camera)
5 Spring washers for use with 1/4˝ screws: 2 (For mounting the camera) or
Spring washers for use with 3/8˝ screws: 2 (For mounting the camera)
6 Camera mounting bracket: 1
Use a bracket made of a material and having a shape that is strong enough to support
the total mass of all units installed, including the camera and lens.
To determine the position of the holes used for mounting the camera, refer to <Bottom
view> on page 11, and make holes with a diameter of 7 mm (to support 1/4-0UNC
mounting screws) or 10 mm (to support /8-16UNC mounting screws).
- 10 (E) -
