Using the Monitor

Installing/Changing the Batteries

1. Remove the battery cover.
2. Remove the used batteries and insert new batteries
into the battery compartment as shown, taking care
that the polarities (+ and -) are correct. Use only R6P,
LR6 or AA batteries.
3. Attach the battery cover.
CAUTION
q Insert the batteries as shown in the battery compartment. If installed incorrectly, the device will not work.
q When (LOW BATTERY mark) blinks on the display, replace all batteries with new ones. Do not mix old and
new batteries. It may shorten the battery life, or cause the device to malfunction.
q Replace the batteries two seconds or more after the device turns off.
q If (LOW BATTERY mark) appears even after the batteries are replaced, make a blood pressure measurement.
The device may then recognize the new batteries.
q (LOW BATTERY mark) does not appear when the batteries are drained.
q The battery life varies with the ambient temperature and may be shorter at low temperatures.
q Use the specified batteries only.
q Remove the batteries if the device is not to be used for a long time.
q The batteries may leak and cause a malfunction.

Connecting the Air Hose

Insert the air connector plug into the air socket firmly.

Connecting the AC Adapter

Insert the AC adapter plug into the DC jack.
Next, connect the AC adapter to an electrical outlet.
q Use the specified AC adapter. (Refer to page E-18.)
Air socket
Air connector plug
DC jack
AC adapter plug
E-7
