4.1. PRESEntatIOn

The LEDI NETWORK TOP can be configured and supervised through a WEB interface.
This interface provides you with the following features:
► Management of network parameters.
► Management of SNMP parameters.
► Management and diagnosis of NTP client software itself.
► Management and diagnosis of pulse output.
Each LEDI NETWORK TOP has its own WEB server that delivers WEB pages. The
WEB site is a JAVA applet. if needed, you can find a JVM on the CDROM in the directory
CDG020\English\Software-tools-Communs\Java J2SE JRE.
To access the WEB site, type-in the address of the LEDI NETWORK TOP in the address
field of your WEB browser (as shown below) and validate the input.
It takes about 20 seconds to load of the JAVA applet. If the load fails, it can be for one of
the following reasons:
► 1. The IP address is invalid.
► 2. A network problem prevent your computer to contact the LEDI NETWORK TOP.
► 3. You don't have a JVM engine installed on your computer.
For the first two reasons, you have to check for the IP address of the LEDI NETWORK
TOP and your network configuration. For the last reason, you have to install the JVM (see
directory CDG020\English\Software-tools-Communs\Java J2SE JRE on the CDROM).
