See the documentation of the NTP server that you use to configure the preference value
9
The different fields of this branch are described below:
► ntpOutBusCardnumber
Number of cards detected on output bus.
► ntpOutBusCardtable
A table that shows all the cards detected on the output bus. Each card is indexed by
its address (1..8 for output cards and 9 for the display). Each entry has the following
format:
• ntpOutBusCardIndex:
Index of this entry (i.e card address). This value can have a value from 1 to 8 (for
output cards) or 9 (for display).
• ntpOutBusCardState:
The state of the card. It can be detected indicating that the card works correctly,
failure if the card don't reply or scrambled if the reply from the card is incorrect.
• ntpOutBusCardType:
Type of the card (see Appendix C – Marking guide for a list of the possible output
cards types).
• ntpOutBusCardDescription:
A textual description of the card.
• ntpOutBusCardActivation:
Indicate if the output of the card activated or deactivated (this feature can be
controlled from the WEB interface). If the card cannot be deactivated, this field has
the value notapplicable.
• ntpOutBusCardTimeZone:
Time-zone for this output. This is displayed as an offset from universal time. This
setting can be changed from the WEB interface.
• ntpOutBusCardDayLightSavingPolicy:
Indicate which day saving time policy is used. If there is no DST, this field has the
value <none>. This setting can be changed from the WEB interface.
• ntpOutBusCardDayLighSavingCurrent:
Indicate if Day Saving Time is in effect (value summertime) or not (value winter-
time). If Day Saving Time is not activated, this field has the value notapplicable.
• ntpOutBusCardTotalOffset:
Indicate current total offset from UTC.
For example the display cannot be deactivated
