6. Installation

Check the radio transmission range before installing the
Telis 6 Chronis RTS mount. The radio range is 20 m through
2 concrete walls.
- Select a location for the wall mount
- Mark the screw locations (vertical spacing: 40 mm)
- Drill, then secure the mount with the screws (use anchors
if required)
- Fit the screw cap
The use of radio appliances (e.g. Hi-Fi radio
headphones) operating on the same frequency
may cause interference and reduce the product's
performance.
Never install the Telis 6 Chronis RTS on or near metal
surfaces as doing so may reduce the radio transmission range.

7. Operation

To switch from manual to automatic
mode, or automatic to manual mode,
briefly press the selection button ( ).

7.1. Manual mode

Manual mode on the Telis 6 Chronis RTS is
used to:
• Send an occasional order to the end-products assigned to the 6 different channels
• Deactivate automatic order programming
For example, channel 1 "ROOM" is used to open the roller shutters of the parents'
bedroom, channel 2 "LIVIN" is used to move the roller shutter in the lounge to the
ideal position to avoid reflections on the computer and TV screens, and channel 3
"TERRA" is used to lower the terrace awning to go and sit outside, etc.
When manual mode is selected, the Sun function is automatically deactivated.
The function will be reactivated at the next programmed
7.1.1. Controlling the channels manually
- Select the channel of the Telis 6 Chronis
RTS to be used with the arrow buttons
( or ): each channel is identified by
a number and the selected name (see
"Customisation of channels" section).
- Briefly press the c, e, or a button
corresponding to the desired order.
- When the intermediate position has been programmed and the end-product is stopped, briefly
press e: the end-product or the group of end-products is activated and goes to the (my) favourite
position.
7.1.2. Changing the name of a channel
See the "Naming a channel" section.
7.1.3. Changing or deleting an end-product in a channel
See the "Assigning or deleting end-products in each channel" section.
Copyright © 2010 Somfy SAS. All rights reserved.
Telis 6 Chronis RTS
40 mm
automatic order.
9
