Parámetros del SmartMotor
(En el Apéndice A se proporciona un Glosario Inglés–Español de Bloques y Parámetros).
BLOQUES DEL NIVEL 1
Preset Speeds
Preset Speed #1
Preset Speed #2
Preset Speed #3
Preset Speed #4
Preset Speed #5
Preset Speed #6
Preset Speed #7
Accel / Decel Rate
Accel Time #1
Decel Time #1
S-Curve #1
Accel Time #2
Decel Time #2
S-Curve #2
Jog Settings
Jog Speed
Jog Accel Time
Jog Decel Time
Jog S-Curve Time
Keypad Setup
Keypad Stop Key
Keypad Stop Mode
Keypad Run Fwd
Keypad Run Rev
Keypad Jog Fwd
Keypad Jog Rev
IMN750SP
Input
Operating Mode
ANA CMD Select
ANA CMD Inverse
ANA CMD Offset
ANA CMD Gain
ANA CMD Filter
Output
Opto Output #1
Zero Spd Set Pt
At Speed Band
Set Speed Point
Overload Set PT
Underload Set Pt
ANA Volt Range
Analog Out #1
Analog Scale #1
V/HZ and Boost
Ctrl Base Freq
Torque Boost
Dynamic Boost
Slip Comp Adj
V/HZ Profile
Max Output Volts
BLOQUES DEL NIVEL 2
Output Limits
Min Output Freq
Max Output Freq
PK Current Limit
PWM Frequency
Custom Units
Decimal Places
Value At Speed
Units of Measure
Protection
External Trip
PWM vs TEMP
Foldback Protect
Miscellaneous
Restart Auto/Man
Restart Fault/Hr
Restart Delay
Stability Comp
Factory Settings
Security Control
Security State
Access Timeout
Access Code
Motor Data
Motor Voltage
Motor Rated Amp
Motor Rated Spd
Motor Rated Freq
Motor Mag Amps
Brake Adjust
Resistor Ohms
Resistor Watts
DC Brake Voltage
DC Brake Freq
Brake On Stop
Brake On Rev
Stop Brake Time
Brake On Start
Start Brake Time
Process Control
Follow IN/OUT
Encoder Lines
Skip Frequency
Skip Freq #1
Skip Band #1
Skip Freq #2
Skip Band #2
Skip Freq #3
Skip Band #3
Synchro Starts
Synchro–Starts
Sync Start Freq
Sync Scan V/F
Sync Setup Time
Sync Scan Time
Sync V/F Recover
Sync Direction
Profile Run
Number of Cycles
RP Restart Mode
SPD#1 Curve/Dir
Profile Time #1
SPD#2 Curve/Dir
Profile Time #2
SPD#3 Curve/Dir
Profile Time #3
SPD#4 Curve/Dir
Profile Time #4
SPD#5 Curve/Dir
Profile Time #5
SPD#6 Curve/Dir
Profile Time #6
SPD#7 Curve/Dir
Profile Time #7
