ACCESSORIES -
P
LATE TO BE CEMENTED
R
ACK OF MODEL 4
with CATAPHORESIS treatment, right-angle, in 2 m - 6,56 feet bars
Ideal for gates weighting up to 2200 kg / 4,800lbs.
R
ADIO TRANSMITTER MOON
MOON 433 - MOON 91
433 code ACG6081 433 code ACG6082
91 code ACG7025 91
code ACG7026
S
PARK
In order to make the systems mentioned above give the best
performances, you need to install an antenna tuned on the frequency of
the radio receiver installed.
N.B. Pay attention to not let the central wire of the cable to came
Into contact with the external copper sheath, since this would
prevent the antenna from working.
Install the antenna vertically and in such a way the remote control can
reach it.
SPARK ANTENNA 91
SPARK ANTENNA 433
SPARK BLINKER WITH IN-BUILT INTERMITTENT CARD
For the connections and the technical data of the optional equipments follow the relevant
handbooks.
code ACG8103
code ACS9050
MOON CLONE
code ACG6093
code ACG5454
code ACG5252
code ACG7059
F
IT SYNCRO
FIT SYNCRO PHOTOCELLS for the wall-installation
The range you can set is 10-20 m, 30÷60ft.
You can fit many couples close together thanks to the synchronising
circuit.
Add the SYNCRO TRANSMITTER
for more than 2 photocells couples (up to 4).
COUPLE OF BUILT-IN BOXES FOR THE FIT SYNCRO
P
AIR OF COLUMNS FOR FIT SYNCRO
h = 0,5 m
B
LOCK
BLOCK KEY SELECTOR FOR WALL-INSTALLATION
BLOCK KEY SELECTOR TO BUILD-IN
P
ROBE
PROBE
The probe detects the motor temperature to operate the heating system
under low temperature conditions, up to -30°C (connect to connector
J8).
G G
B B
code ACG8026
code ACG8028
code ACG8051
code ACG8057
code ACG1053
code ACG1048
code ACG4665
