: keep this instruction manual
attention
safe and observe the important safety
requirements contained herein. Failure to
comply with the requirements may cause
damage and serious accidents.
i
mportant For the installer
- The control unit must be supplied by SELV
(safety extra low voltage) or SELV equiva-
lent power limited source. The loads con-
nected to the relays must also comply
with an extra low safety voltage.
- All operations that require the casing to
be opened (installation, programming,
repairs, etc.) must be performed only by
qualified personnel.
- The fixing of power and connection cables
must be secured through the use of optional
cable glands supplied.
- Fix the control unit to a wall, using the
relevant support which is fitted to the cas-
ing, in such a way as to leave said support
facing downwards and insert the fixing
screws in the special holes.
the product:
The Single Channel Receiver
BeSAFE RX NEW
complies with the prescriptions of Directives
RED 2014/53/EU and EMC 2014/30/EU.
TECHNICAL DATA:
- Power supply
- Max. consumption
- Op. remote control
- Op. transponder
- Storable devices different from each other : 1000 Max
- 2 control relays
- Operating temperature
- Dimensions
- Container
- Protection rating
- Remote control capacity in open space
10
: 12-24V AC-DC
: 6 W
: 12-18 Bit or Rolling Code
: BeSafe Card or Besafe Key
: 30VDC 1A
: -10°C ÷ 55°C
: 110x121x47mm
: ABS (UL94V-0)
: IP54
: 30-70 metres
