LS9 Engine Specifications
Type ................................................. 6.2L Gen IV Small Block V8
Displacement ..................................................... 376 cubic inches
Bore x Stroke .............................................4.065 inch x 3.62 inch
Compression ........................................................................9.1:1
Supercharger Boost Ratio ..................................................10.5:1
Block ..................Cast aluminum, six bolt cross-bolted main caps
Cylinder Head ................................Cast aluminum rectangle port
Valve Diameter (Intake/Exhaust) ............................ 2.16"/1.59"
Chamber Volume .................................................................. 68cc
Crankshaft ............................... Forged Steel, internally balanced
Connecting Rods ................................................Forged Titanium
Pistons ..............................................................Forged aluminum
Camshaft ...................................................Hydraulic roller tappet
Lift ................................................... 562" intake, .558" exhaust
Duration .............. 211° intake, 230° exhaust @.050" tappet lift
Rocker Arm Ratio ................................................................1.7:1
Oil Pressure (Minimum, with hot oil) ............ 6 psig @ 1000 RPM
. ..............................................................18 psig @ 2000 RPM
. ..............................................................24 psig @ 4000 RPM
Recommended Oil ............5w30 Dexos 1 motor oil or equivalent
................... (must meet GM4718M specification, which will be
.......................................................... specified on the oil label)
Oil Filter .................................... AC Delco Part Number UPF48R
Fuel........................................... Premium unleaded - 92 (R+M/2)
Maximum Engine Speed .............................................6600 RPM
Spark Plugs ........................................................... GM 12571165
................................................................... AC Delco # 41-104
Spark Plug Gap .....................................................................040"
Firing Order ......................................................... 1-8-7-2-6-5-4-3
Information may vary with application. All specifications listed
are based on the latest production information available at
the time of printing.
