6. CONNECTIONS OF MANUAL OR AUTOMATIC INTERLOCKING
To obtain a manual or automatic
interlocking between two Thesis 2.o
solenoid
locks
equipped
appropriate software and connected with
an encrypted communication channel,
proceed as follows:
1.
Connect the PIN1 of both locks
(communication channel) with each
other, as well as the corresponding
PIN2 and PIN3 with the same power
source,
but
do
NOT
recommend that you do not insert the
connectors already red in each lock
(see figure shown on the side).
Insert the JP4 jumper in one
2.
of the two locks and by pressing
either of the two buttons of the
same, only power this lock (in-
sert the wired connector). Wait at least 2
seconds before releasing the button.
1-18
3.
figured lock ON (step 4), locate
with
the
the lock without the JP4 jumper;
while pressing either of the two
buttons, start power on this lock as well
(insert the wired connector). Wait at least
2 seconds before releasing the button.
After a few seconds, the communication
between the two locks will be activated,
power:
we
and both locks will operate in the inte
locking mode laid out by the software
(manual or automatic).
NOTE
The above procedures are performed with
the doors in opened position.
Keeping the previously con-
Example of connection between two
locks interlocked
12345678
12345678
NOTE
If required by the specifications of
the system, connect the indicator
lights to the relay of the "secured
door status" of each lock (PIN
4/5/6)
and
the
corresponding
opening button (PIN 7/8 optically
insulated entry). Anticipate the use
of an adequate power supply (one
lock alone consumes 15W).
