1 User
The axis interface type SPC−AIF−INC is used to connect
pneumatic axes to the SPC200 Smart Positioning Con
troller. It establishes the link with the MPYE−... propor
tional directional control valve and a drive intended for this
purpose with integrated magnetic incremental measuring
system from Festo, e.g. the standard cylinder type DNCI−...
For the use of the axis interface type SPC−AIF−INC the fol
lowing versions are required:
SPC200 with operation system as from version V4.80
WinPISA as from version 4.40
Detailed information on the axis interface can be found in
the P.BE−SPC200−... User Manual.
Caution
Pay strict attention to the following instructions shown
therein:
safety guidelines
specifications for the use of each module and compo
nent.
Warning
Prior to any installation or maintenance work, switch off
the power sources in the following sequence:
1. Compressed air supply
2. Load supply and operating voltage supply for the
SPC200.
Festo SPC−AIF−INC 0406NH English
instructionsEnglish
13
