ASSEMBLY
STEP 13 - ASSEMBLE THE SUPPORT
NAME
5
Flat washer
M10
NAME
2
Hex Nut
M10
20 NAME
Internal Hex Head Screw
M10X130
NAME
21
Fixation plate
NAME
22
Plug
NAME
23
Hex Head Screw
M10X20
P NAME
Cam support
Tools
Tools
Allen 8 mm
Fix wrench 17 mm
To assemble that
Sticker thread
we suggest 2 people
lock medium torque
QTY
10x
QTY
2x
QTY
2x
QTY
1x
QTY
6x
QTY
6x
P
22
5
23
5
23
5
22
23
28
Figur e 13 -1
22
23
5
5
23
22
Figur e 13 -2
2
5
5
21
20
