Connecting the discharge pipe
The Sanicondens® Pro/Eco discharge connection must be connected to the flexible vinyl hose D.
- Unroll the flexible hose D.
- Insert the hose into the discharge connection that has a built-in non-return valve (see fig. 5).
- Position the flexible hose in the upmost vertical position possible to avoid any kinking. It is recommended to make a
smooth turn to avoid the hose from kinking.
- Secure the hose by using the clamp E supplied (fig. 5).
The hose has an inner diameter of 10 mm and can be connected to a PVC pipe of larger diameter by a plastic reducer
connection F (fig. 5.1). Provide a cable tie to secure the connection (fig. 5.2).
The Sanicondens® Pro/Eco is fitted with a non-return valve to prevent re-activation.
3.3 CONNECTING THE ALARM (SANICONDENS® PRO)
Sanicondens® Pro is fitted with a detection system that can cut off the power supply to the connected appliance if the
water level rises too high. To connect the detection system, connect the other set of cables, black and grey (see "Alarm"
label), to the appliance (refer to the instructions of the appliance). See fig. 7.
NOTE: It is possible to connect the detection system to an external alarm (audible or visual, from1.5V to 230V) by
changing the connection of the detection system. Sanicondens® Pro is controlled by a dry contact supplied NC
(normally closed). To connect the external alarm, this contact must be changed to NO (normally open, fig. 10). To do this,
open the cover (fig. 8), unplug the grey wire from its location and plug it to the free contact above (fig. 9).
- ATTENTION : the connection of the detection system to the safety system of the connected appliance is
mandatory. The guarantee does not cover damage caused if the alarm is not connected.
- The maximum current admissible for our detection system is 4 A.
- To protect the electrical components in the Sanicondens Pro, once the alarm has been triggered, any water continuing
to fill the tank comes out through the overflow outlets of the tank.

3.4 MAINS CONNECTION

Connect the power cable G to the Sanicondens® Pro/Eco (fig. 6) and then to the main power. Comply with local
installation requirements.
3.5 USE
Functional test
Before turning on the pump, make sure you remove the protective lock pin from the rear of the device. Fig. 4.
- Pour water into the tank.
- Check that the pump starts and stops when the water level drops.
- Check that there are no leaks in the connections.
Sanicondens® Pro/Eco is ready to use. Example of an installation of a Sanicondens® Pro/Eco: see pg. 6.
STANDARDS
4
Sanicondens® Pro/Eco conforms to the European directive on low voltage.
INTERVENTIONS
5
Disconnect electrical supply before working on the unit!
5.1 MAINTENANCE
This device does not require any special maintenance.
5.2 TROUBLESHOOTING
Fault detected
The pump doesn't start.
The pump does not lift.
GUARANTEE
6
Sanicondens® Pro/Eco is guaranteed for 2 years for parts and labour, subject to correct installation and use of the unit.
INSTRUCTIONS INTENDED SOLELY FOR QUALIFIED PROFESSIONALS
INSTRUCTIONS INTENDED SOLELY FOR QUALIFIED PROFESSIONALS
Probable causes
The pump is not connected to the power
supply.
The lock pin has not been removed.
The unit is not leveled.
Power outage.
Float blocked.
Condensates inlet pipe blocked.
Noon-return valve blocked.
Discharge pipe blocked.
15
Action needed
Plug in the unit.
Remove the lock pin.
Check the unit with a leveling tool.
Check the main power.
Clean the tank.
Clean the inlet pipe.
Clean the valve.
Clean the discharge pipe.
