Setup

Loose Parts

Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
4
Note:
The battery pack is not fully charged when you purchase it. Before using the tool for the first time, refer
to
Charging the Battery Pack (page
1
Mounting the Battery
Charger (Optional)
No Parts Required
Procedure
If desired, mount the battery charger securely on a
wall using the wall-mount key holes on the back of
the unit.
Make sure to mount it indoors (such as a garage or
other dry place), near a power outlet, and out of the
reach of children.
Refer to
Figure 1
for assistance in mounting the
charger.
Note:
Slide and twist the charger over the
appropriately positioned hardware to secure the
charger in place.
Description
No parts required
Connector knob
Auxiliary handle
Guard
Phillips head screw
11).
Qty.
Mount the battery charger.
1
Unfold the handle.
1
Install the auxiliary handle.
1
Mounting the guard to the base of the
trimmer.
4
7
Use
Figure 1
g194202
