INSTALL BATTERY

1. Insert your finger tip into the slot (1), then push down on
top of the battery cover and slide it off to remove (2).
2. Slide the battery into the slot (3) by aligning the contacts
and press down (4) until you hear the "click".
Correct
3. Align the cover tabs with the slots on the back of the
device and slide the battery cover onto the unit until it
snaps into place.
If the battery is not correctly placed in the compartment,
the handset will not turn on and/or the battery may detach
during use.
Correct

REMOVE BATTERY

1. To remove the battery cover, insert your finger tip into
the slot (1), then push down on top of the battery cover
and slide it off (2).
16
Incorrect
Incorrect
2. Insert your fingernail into the slot (3) and lift the battery
from the compartment (4).
3. Align the cover tabs with the slots on the back of the
device and slide the battery cover onto the unit until it
snaps into place.

CHARGING YOUR BATTERY

1. Connect the USB data cable into the cableless wall
adapter.
2. Plug the USB data cable into the phone' s Charging/
Data Jack (making sure to align the connector as it
appears in the image to the right) and the wall
adapter end into an electrical outlet.
If the battery connector is not properly aligned, damage could occur to the charging
connector and the phone may not charge.
Correct
Correct
3. To remove the Wall Charger, pull the charger from the
device.
Incorrect
Incorrect
