Item Part No.
339974
1
2 340023
3 400192
4 400202
5 400258
6 444718
7 444754
8 444849
9 446142
10 5002918
11 2811364
12 2811365
13 3005934
14 3005981
15 4128509
16 443828
17 5002919
18 2811547
19 447224
20 416911
21 444782
GROOM MASTER SAND TRAP RAKE
Qty. Description
2 Connector, 4-6 Straight Thread
2 Connector, Hydraulic
1 Screw, 5/16-18 X 1-1/2" Hex Head
1 Screw, 5/16-18 X 2-3/4" Hex Head
2 Screw, 3/8-16 X 3/4" Hex Head
3 Locknut, 5/16-18 Center
4 Locknut, 5/16-24 Center
2 Locknut, 3/4-10 Center Jam
2 Lockwasher, 3/8 Heavy
1 Actuator, Tilt Steering Assembly
1 Wheel Assmebly, Steering
1 • Cap, Steering Wheel
2 Bolt, Shoulder
1 Bracket, Steering Pump
1 Valve, Power Steering
1 • Nut, 5/8-11
1 Cable, Actuator
1 Washer
1 Lockwasher, 5/8 Internal Tooth
2 Screw, #10-24 X 1/2" Self Tap
2 Locknut, #10-24 Center
Serial Numbers/Notes
> Change from previous revision
