Cascade installation example.
Remove JP1 jumper from all of the EL561 monitor
modules (see page 67), except on the one
where the twisted pair cable finishes
(don't uses the video output).
Distributed installation example.
Remove JP1 jumper from all of the video distributors
and EL561 monitor modules (see page 67),
except on the ones where the twisted pair cable
finishes (don't use the video output).
M
p
Don't modify the JP2 jumper of the video distributors.
IMPORTANT.
If the system has one door panel only,
override the wiring to the second door panel.
If the system has more than one door panel, wire
the rest of panels as shown on the diagram.
FA-805
PRI
0 110 230
~1
~1
~2
Main
INSTALLATION DIAGRAMS
