ASSEMBLY INSTRUCTIONS / INSTRUCTIONS D'ASSEMBLAGE /
INSTRUCCIONES DE ENSAMBLAJE
1
- Wood dowel -20- should be pushed into the end of the hole.
- Pasador de madera -20- debe ser empujado al final del orificio.
- Cheville en bois -20- devrait être poussé dans la fin du trou.
20
20
T
20
20
20
20
AF (X2)
20
20
- Insert 20 (X40) into L(X2), M, R, S, T, U, W, Z, AE(X2), AF(X2) , Insert 23 (X8) into N(X2)
- Insérer 20 (X40) dans L(X2), M, R, S, T, U, W, Z, AE(X2), AF(X2) , Insérer 23 (X8) dans N(X2)
- Insertar 20 (X40) en L(X2), M, R, S, T, U, W, Z, AE(X2), AF(X2), Insertar 23 (X8) en N(X2)
