FactorRACK FR-419 Manual De Usuario página 13

s
peciFications
»Electric
• Power Supplu: 400V, 50/60H
• Max. voltage: -20% y +10%
»Mains circuit breaker
• 4 x 16A D (power)
• 2 A C (controll)
» Input connectors
• Power connector: 1x CEE 5 pole 32 A
»Out connectors
• 4 x CEE 4 pole 16A
• 1 x 16 pole Harting 16A
»Safety
• 1 x Emergency button
»Physical
• Size: 483 x 440 x 134 mm
• Rack 19" format: 4U
• Weight: 9,0 kg
• Housing: compact strong metal housing
s
izes
L1 L2 L3 MOTOR 1
PHASES
CENTRAL CONTROL
UP 0D
MAINS CONTROL
CIRCUIT
FR-419
FactorRack
Chainhoist controller
195
13
482
MOTOR 2M OTOR 3 MOTOR 4S TOP
PRESS
OWNU P - 0 - DOWN UP - 0 - DOWNU P - 0 - DOWN
RUN
PRESS
Manual de usuario / User Manual | FR-419 Chainhoist controller | Rev. Jan.2016 | www.siluj.com
e
nglish
»Thermal
• Minimum ambient working temperature: -10º C
• Maximum ambient operating temperature: 45º C
• Environmental protection: IP20
»Ordering information
• Code: FR-419
• Description: Chainhoist controller 4 ch
»Included in orders
• 1 x FR419 Chainhoist controller
• 1 user manual
»Optional accessories
• Flighcase rack 19" 4U standar (7007004)
• Flightcase rack 19" 4U anticho (7007104)
MOTOR
1 - 4
MOTOR
1
440
MOTOR 1 MOTOR 2M OTOR 3 MOTOR 4
Pin Phase PinP Phase in Phase Pin Phase
1L 1L 59 1L 1L 13 1
2L 2L 61 2L 01 2L 4 2
DEVELOPED AND MANUFACTURED IN EU
3L 3L 71 3L 11 3L 5 3
48 12 16
POWER INPUT
AC 230V ~ 3 PHASE
32A / PHASE
MOTORM OTOR MOTOR
234
CAUTION
RISK OF ELE CTRI C SHOCK. DO NOT OPEN.
To prevent electrical shock do not remove
the cover. No user ser viceable parts inside.
Refer service to qualified personnel only.
