Gentile Signora, Egregio Signore
ci congratuliamo con Lei per la Sua nuova Cimbali.
Con questo acquisto Lei ha scelto una macchina per caffè
espresso d'avanguardia costruita secondo i più avanzati
principi della tecnica moderna; una macchina che non
e funzionalità ma mette a Sua disposizione tutti gli strumenti
per darLe la "sicurezza di lavorare meglio".
Il consiglio di dedicare un poco di tempo alla lettura di questo
Libretto di Uso e Manutenzione nasce dal desiderio di
desiderio che siamo certi Lei condividerà pienamente.
Le auguriamo buon lavoro.
GRUPPO CIMBALI S.p.A.
F
Cher Client,
Nous vous félicitons pour l'acquisition de votre nouvelle
Cimbali.
Avec cet achat vous avez choisi une machine à café
moderne, construite selon les principes les plus avancés
de la technique d'aujourd'hui, une machine qui vous offre
qui met ê votre disposition tout ce dont vous avez besoin
pour obtenir un bon travail.
Le conseil que nous vous donnons de consacrer un peu
de votre temps à la lecture de cette brochure vient du
désir que nous avons de vous aider à atteindre une bonne
connaissance de votre nouvelle machine.
Nous sommes certains que vous serez du même avis.
Avec nos meilleurs souhaits de bon travail.
GRUPPO CIMBALI S.p.A.
E
Estimado Cliente,
nos felicitamos con Usted para su nueva Cimbali.
Con esta compra Usted ha escogido una máquina para
café a la vanguardia, construida según los principios mas
adelantados de la técnica moderna; una máquina que no
también le da todo lo que Usted necesita para alcanzar
la garantía de un buen trabajo.
Le aconsejamos de poner un poco de su atención en la
lectura de este manual, consejo que nos viene del deseo
de aiudarle a lograr un buen conocimiento de su nueva
máquina.
Estamos seguros que Usted tiene la misma opinión.
Con un deseo particular de buen trabaio
GRUPPO CIMBALI S.p.A.
All manuals and user guides at all-guides.com
1
GB
Dear Customer,
We congratulate with you for your new Cimbali.
With this purchase you've chosen an up to date machine,
built after the most advanced principles of modern
technology, a unit, which gives you not only a perfect
your disposal everything you need for a good working.
The advice we give you of spending a bit of your time in
reading this manual comes from our desire of helping you
in reaching a good knowledge of your new machine.
With our best wishes of a good work.
GRUPPO CIMBALI S.p.A.
D
Sehr geehrter Kunde,
Wir gratulieren lhnen zur lhrer neuen Cimbali und heissen
sie in unserem Kundenkreis willkommen. Mit diesem Gerät
haben Sie eine Maschine ausgewählt, die nach den letzten
technischen Entwicklungen auf diesem Sektor gebaut
wurde: eine Maschine die mehr als die perfekte Synthese
zwischen Leistungsfähigkeit und Funktionalität anbietet:
nämlich die Gewissheit, ein
Aufgaben gewachsenes Gerät zu besitzen.
Wir empfehlen lhnen dieses Handbuch zum Studium,
wissend, dass Sie damit lhre Kenntnisse über lhre neue
Maschine vertiefen können.
Wir verbleiben mit unseren besten Wünschen für ein gutes
Arbeiten mit lhrem neuen Gerät.
GRUPPO CIMBALI S.p.A.
P
Exmª. Senhora, Exm°. Senhor,
Felicitamo-nos e a si pela sua nova Cimbali.
Com deste acquisição escolheu uma máquina para café
de vanguarda, construída segundo os mais avançados
principios da técnica moderna, uma máquina que está não
somente em condições de lhe oferecer uma sintese perfeita
todos os instrumentos para dar-lhe a "segurança de
trabalhar melhor".
O conselho de dedicar um pouco de tempo à leitura deste
livreto de uso e manutenção nasce do desejo de o ajudar
a tomar familiaridade com a sua nova máquina; desejo
que estamos certos partilhará plenamente.
Desejamos-lhe bom trabalho.
GRUPPO CIMBALI S.p.A.
betriebsicheres, seinen
Code 936-036-000 (rev. 0849)
