Figure C, D: Wire Drive Assembly; Miscellaneous Items (Not Shown In Figure A, B, C, D) - Lincoln Electric Oerlikon CITOSTEP 255C Manual Del Usuario

Item Description
WIRE DRIVE ASSEMBLY
71 FEED PLATE
72 INLET GUIDE
73 ADAPTER
74 FIXING CAP
75 METAL COVER
76 PRESSURE ARM COMPL.
77 SPRING PRESSURE ARM
78 FIXING ARM COMPL.
92 MOTOR
93 WOODROF KEY
94 EURO SOCKET COMPLETE
95 OUTLET GUIDE
96 SLEEVES
97 SLEEVES
98 STICKER

Miscellaneous Items (not shown in figure A, B, C, D)

Item Description
99 WIRING HARNESS (PRIMARY)
100 WIRING HARNESS (SECONDARY)
101 WIRING HARNESS
102 WIRING HARNESS
Spare Parts - Electrical Schematic

Figure C, D: Wire Drive Assembly

Part Number
0744-000-160R
0744-000-219R
0744-000-224R
0744-000-227R
0744-000-216R
0744-000-218R
0744-000-221R
0744-000-220R
0744-000-223R
0744-000-229R
0646-231-102R
C-2985-006-2R
D-1829-066-4R
1361-599-720R
1361-599-565R
2719-107-732R
Part Number
R-5041-176-1R
R-5041-177-1R
R-5041-185-1R
R-5041-186-1R
6
QTY 1 2 3 4
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
1 X X
4 X X
2 X X
1 X X
QTY 1 2 3 4
1 X X - -
1 X X - -
1 - X - -
1 X - - -
Spare Parts - Electrical Schematic
5 6 7
5 6 7
- -
- -
- -
- -
