Before assembling your product, please take a few minutes to check the contents
REF.
DESCRIPTION
NO.
1 CONTROL BASE
2 SIDE COVER HINGE BASE
3 SIDE COVER HINGE FIXER
4 CONTROL BASE SIDE COVER
5 CONTROL PANEL
6 CONTROL PANEL BOLT WRENCH
7 SPA/COVER INFLATION HOSE
8 SPA CONTROL INLET/OUTLET O-RING
9 SPA CONTROL AIR INLET O-RING
10 SPA DRAIN PLUG
11 SPA DRAIN VALVE ADAPTOR
12 FILTER CARTRIDGE HOUSING
13 FILTER CARTRIDGE
14 FILTER CARTRIDGE HOUSING LID
15 INLET/OUTLET PLUG
16 SPA TUB
17 SPA COVER
18 SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
19 GROUND CLOTH
20 CHEMICAL DISPENSER
21 TEST STRIPS
22 WRENCH
23 AIR PRESSURE RELEASE VALVE CORE
24 HOSE ADAPTOR (PRE-INSTALLED WITH #7)
25 MALE BUCKLE
26 FEMALE BUCKLE
27 DEFLATION OUTLET CAP
28 DEFLATION HOSE ADAPTOR
29 SPA FILTER MOTOR
30 PANEL FIXER
31 SUCTION FITTING
When ordering parts, be sure to quote the model number and part numbers.
S AVE THESE INSTRUCTIONS
