PROGRAMMABLE PARAMETERS:
GAS CYCLE: confirmation signal of gas cycle active.
0V = gas cycle inactive
24V= gas cycle active
SAFETY LIMIT WARNING: confirmation signal of safety limit no warning active.
SAFETY LIMIT ALARM: confirmation signal of no alarms.

3.1 Configuration digital inputs

In this manual, all instructions will be referred to:

"Configuration standard digital inputs"

3.1.1 Configuration standard digital inputs
0V = 0 Input opened or not connected (low state)
24V = 1 Input closed or powered (high state)

3.1.2 Configuration inverted digital inputs

0V = 1 Input closed (low state)
24V = 0 Input opened or powered (high state)
Consult the section "Set-up parameter 400" (Genesis ... repair manual)
0V= safety limit warning active
24V = safety limit warning inactive
0V = safety limit alarm active
24V = safety limit alarm inactive
23
