CUTTING

CUTTING PREPARATION

Place the angle attachment into the
cutter head and push it as much as you
can to the bottom. Change the cutting
angle from 90° to 45° as needed.
WARNING: Do not put your fingers
against the sharp edge of the blade at
any time.
STRAIGHT CUT (90° ANGLE)
Insert material between the cutting blade
and the base as shown and hold the
material with the flooring holding bar ,
then push handle down to complete
a cut.
WARNING: Do not put your fingers
against the sharp edge of the blade at
any time.
ANGLE CUT (45° ANGLE)
Install the 0-45° Attachment as shown.
Position the cutting angle to the
45° angle.
WARNING: Do not put your fingers
against the sharp edge of the blade at
any time
- 3 -
