INSTALLATION

Installation
Categories of people
Adult man
Adult woman
Children 5-8 years old
Children 8-11 years old
Children 11-14 years old
Wheelchair users
™
12 | Ultronic Plus & Premium Hand Dryers
Height
55˝ (1400 mm)
53¾˝ (1365 mm)
40½˝ (1028 mm)
44½˝ (1128 mm)
47½˝ (1208 mm)
45¼˝ (1150 mm)
11. Installation

11.1 Fitting the wall mounting bracket

The appliance is intended for wall mounting using the wall mount-
ing bracket supplied.
Place the appliance on a soft underlay to prevent damage to
the surface.
1.
Undo the locking screw on the underside of the appliance
using the Torx key included in the standard delivery.
Pull the wall mounting bracket downwards.
Remove the wall mounting bracket from the appliance.
2.
3.
