MIDI Implementado
This message is transmitted with the MIDI channel set at the "MIDI Control Channel (*1)."
"None Registered Parameter Number" value is equal to the "Start Address" referred in "2.
Address Map for Data Transfer" section."
The address value range of "None Registered Parameter Number" is "00 00 00 - 00 7F 7F."
(*1) See "2. Address Map for Data Transfer" section.
Data Entry (MSB/LSB)
Status Second
BnH 06H
BnH 26H
n = MIDI Channel No.: 0H - FH (ch.1 - ch.16)
mm = upper byte corresponding to the parameter assigned with NRPN
ll = lower byte corresponding to the parameter assigned with NRPN
<Ex> mmH llH = 40H 00H = -8192
= 7FH 7FH = -1
= 00H 00H = 0
= 3FH 7FH = +8191
This message is received at the following case.
When the "MIDI Control Type (*1)" parameter is set to "NRPN" and moreover the MIDI
channel value with the message is same as the "MIDI Control Channel (*1)."
After this message is received, the parameter is modified referring to the "None Registered
Parameter Number."
When the "None Registered Parameter Number" is not set, this message was ineffective.
The setting value range of each parameter number is different.
See "2. Address Map for Data Transfer" section.
This message is transmitted at the following case.
When the VM-Link is not connected and moreover "MIDI Control Type (*1)" is set to
"NRPN" and moreover the parameter is modified.
This message is transmitted with the MIDI channel set as "MIDI Control Channel (*1)."
(*1) See "2. Address Map for Data Transfer" section.
Data Increment
When the VM-Link is not connected and moreover the "MIDI Control Type (*1)" parameter
is set to "NRPN" and moreover the MIDI channel value is same as the "MIDI Control
Channel (*1)" value.
After this message was received, the parameter is increased referring to the "None
Registered Parameter Number."
The VM-7200/7100 doesn't transmit this message.
Status Second
BnH 60H
n = MIDI Channel No.: 0H - FH (ch.1 - ch.16)
Increment the effect parameter selected with NRPN.
(*1) See "2. Address Map for Data Transfer" section.
Data Decrement
When the VM-Link is not connected and moreover the "MIDI Control Type (*1)" parameter
is set to "NRPN" and moreover the MIDI channel value is same as the "MIDI Control
Channel (*1)" value.
After this message was received, the parameter is decreased referring to the "None
Registered Parameter Number."
The VM-7200/7100 doesn't transmit this message.
Status Second
BnH 61H
n = MIDI Channel No.: 0H - FH (ch.1 - ch.16)
Decrement the effect parameter selected with NRPN.
(*1) See "2. Address Map for Data Transfer" section.
Pitch bend Change
Status Second
EnH llH
38
Third
mmH
llH
Third
00H
Third
00H
Third
mmH
n = MIDI Channel No.: 0H - FH (ch.1 - ch.16)
mm, ll = Pitch Bend Value: 00 00H – 40 00H – 7F 7FH (-8192 – 0 – +8191)
Set the pitch bend value of third byte to the parameter which is designated with the MIDI
channel number and the pitch bend value of the second byte.
Parameters and Pitch bend Messages
Message Parameter Contents and remarks
--------------------------------------------------------------------------
E0H 00H mmH Input Master Fader Level - CH 1
: :
: :
E0H 2FH mmH MultiIn Master Fader Level - CH 24
--------------------------------------------------------------------------
E0H 30H mmH Main Master Level
: :
--------------------------------------------------------------------------
E0H 31H mmH Input Main Send Pan - CH 1
: :
: :
E0H 60H mmH MultiIn Main Send Pan - CH 24
--------------------------------------------------------------------------
E0H 61H mmH Main Master Balance
: :
--------------------------------------------------------------------------
E0H 62H mmH Pre Amp Input Gain - CH1
: :
E0H 79H mmH Pre Amp Input Gain - CH24
--------------------------------------------------------------------------
E0H 7AH mmH (Reserved)
--------------------------------------------------------------------------
E1H 00H mmH Input Bus 1 Send Level - CH1
: :
: :
E1H 2FH mmH MultiIn Bus 1 Send Level - CH24
--------------------------------------------------------------------------
E1H 30H mmH Input Bus 2 Send Level - CH1
: :
: :
E1H 5FH mmH MultiIn Bus 2 Send Level - CH24
--------------------------------------------------------------------------
E1H 60H mmH Input Bus 3 Send Level - CH1
: :
: :
E2H 0FH mmH MultiIn Bus 3 Send Level - CH24
--------------------------------------------------------------------------
E2H 10H mmH Input Bus 4 Send Level - CH1
: :
: :
E2H 3FH mmH MultiIn Bus 4 Send Level - CH24
--------------------------------------------------------------------------
E2H 40H mmH Input Bus 5 Send Level - CH1
: :
: :
E2H 6FH mmH MultiIn Bus 5 Send Level - CH24
--------------------------------------------------------------------------
E2H 70H mmH Input Bus 6 Send Level - CH1
: :
: :
E3H 1FH mmH MultiIn Bus 6 Send Level - CH24
--------------------------------------------------------------------------
E3H 20H mmH Input Bus 7 Send Level - CH1
: :
: :
E3H 4FH mmH MultiIn Bus 7 Send Level - CH24
--------------------------------------------------------------------------
E3H 50H mmH Input Bus 8 Send Level - CH1
: :
: :
E3H 7FH mmH MultiIn Bus 8 Send Level - CH24
--------------------------------------------------------------------------
E4H 00H mmH Input Bus 9 Send Level - CH1
: :
: :
E4H 2FH mmH MultiIn Bus 9 Send Level - CH24
--------------------------------------------------------------------------
E4H 30H mmH Input Bus 10 Send Level - CH1
: :
