MIDI Implementado
06H General Information (sub ID #1)
01H Identify Request (sub ID #2)
F7H EOX (End of System Exclusive Message)
The message is used to request the particular information of the VM-7200/7100. If this
message is received right after the power is on, Device ID of the received message is set to
the Device ID of the VM-7200/7100.
If the first received message's Device ID is 7FH, the VM-7200/7100's Device ID is set to the
10H (cascade slave processor = 11H), default value.
The VM-7200/7100 does not transmit this message.
If the VM-7200/7100 received the message and the device ID of the received message is
same as its device ID or 7FH, the VM-7200/7100 transmits the following Identity Reply
message.
Status Data Bytes
F0H 7EH, Dev, 06H, 02H, 41H, 1EH, 01H,
nnH, 00H, vvH, 00H, ssH, ssH
Byte Description
F0H Status of System Exclusive Message
7EH Universal System Exclusive Message Non Realtime Header
Dev Device ID
06H General Information (sub ID #1)
02H Identify Request (sub ID #2)
41H Manufacturer ID (Roland)
1EH 01H Device Family Code (VM-7200/7100)
nnH 00H Device Family No. (VM-xxxxx)
0:Reserved, 1:VM-7100, 2:VM-C7100, 3:VM-7200, 4:VM-C7200
vvH 00H Option Available No.
0 0 x x - x x x x
| | | | | +—— Effect Board A
| | | | +———— Effect Board B
| | | +—————— Effect Board C
| | +———————— R-BUS Board
| +———————————— Cascade Board
+—————————————— 7100/7200
ssH ssH Software Revision Level
F7H EOX (End of System Exclusive Message)
MIDI Machine Control Commands
Status Data Bytes
F0H 7FH, Dev, 06H, aaH, ..., bbH
Byte Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Message Realtime Header
Dev Device ID (or 7FH)
06H MMC Command Message
aaH Command
: :
bbH Command
F7H EOX (End of System Exclusive Message)
(*) see "3. MIDI Machine Control" section
MIDI Machine Control Responses
Status Data Bytes
F0H 7FH, Dev, 07H, aaH, ..., bbH
Byte Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Message Realtime Header
Dev Device ID
07H MMC Response Message
aaH Response
: :
bbH Response
F7H EOX (End of System Exclusive Message)
(*) see "3. MIDI Machine Control" section
40
Status
F7H
Status
F7H
Status
F7H
Data Transfer (RQ1, DT1)
Data Request (RQ1)
Status Data Bytes
F0H 41H, Dev, 00H, 1EH, 11H,
aaH, bbH, ccH, ssH, ssH, Sum
Byte Description
F0H Status of System Exclusive Message
41H Manufacturer ID (Roland)
Dev Device ID
00H 1EH Model ID (V-Mixer)
11H Command ID (RQ1)
aaH Address MSB
bbH Address MID
ccH Address LSB
ssH Size MSB
ssH Size MID
ssH Size LSB
Sum Check Sum
F7H EOX (End of System Exclusive Message)
The message is used to request data to the VM-7200/7100.
The VM-7200/7100 does not transmit this message.
The VM-7200/7100 transmits the requested data using Data Set (DT1) under following
condition when it received the message.
1 The requested address correspond to the specified parameter base address of the
VM-7200/7100.
2 The requested size is over 1 byte.
Data Set (DT1)
Status Data Bytes
F0H 41H, Dev, 00H, 0EH, 12H,
aaH, bbH, ccH, ddH, ..., eeH, Sum
Byte Description
F0H Status of System Exclusive Message
41H Manufacturer ID (Roland)
Dev Device ID
00H 1EH Model ID (V-Mixer)
12H Command ID (DT1)
aaH Address MSB
bbH Address MID
ccH Address LSB
ddH Data
: :
eeH Data
Sum Check Sum
F7H EOX (End of System Exclusive Message)
The message is received under the following condition.
If VM-Link is not connected, and the device ID on the message is same as that of the receive
device, and the address on the message correspond to the specified parameter base address,
the received data are stored from the specified parameter base address.
If the interval of received messages is shorter than 20 msec, the VM-7200/7100 can not work
the receive message procedure correctly.
The message is transmitted under the following condition.
When the VM-7200/7100 transmit the data on the requested parameter after receiving the
Data Request message (RQ1).
See "2. Data Transfer Address Map" for more details of the transfer parameters.
Status
F7H
Status
F7H
