Description Of The Components - Zhermack FURNACE DM 4R Manual De Usuario

MAINTENANCE AND USE MANUAL
A. Aspirator (optional Code C305319)
B. Door open/close handle
C. Magnetic closure
D. Control panel (see section 3.5)
E. Oven chamber door
F. Door microswitch
A. Aspirator (optional Code C305320)
B. Door open/close handle
C. Magnetic closure
D. Control panel (see section 3.5)
E. Oven chamber door
F. Door microswitch
G. Ceramic air bleeder
FURNACE DM
EN

Description of the components

G. Ceramic air bleeder
H. Power lead
I. Fuses
L. Hood socket
M. Aspirator socket
TABLE OF THE COMPONENTS DM 4R
Description of the components
H. Power lead
I. Fuses
L. Hood socket
M. Aspirator socket
N. Rotation pan
O. Led
P. On/off switch
