Using the Dynamic Search
Both the sources and destinations areas contain a search icon, which allows you to
search for text dynamically. This is useful if you have many pushbuttons and quickly
want to locate a pushbutton with a specific name. As you type the name you wish to
search for, the pushbuttons that are displayed will be dynamically filtered.
The word 'ATEM' is entered into the Destinations
Search Box and the filtered results are displayed

Blackmagic Videohub Control at a Glance

Title Bar shows
Videohub type
Settings Divider Bar
Click and drag the window edges to resize Blackmagic Videohub Control to fit
your screen size. Drag the Divider Bar up or down to reveal more or less of the
'Sources' and 'Destinations' areas and use the Scroll Bars to scroll the areas

Settings Menu

Select Videohub
Select from a list of Videohubs that are currently connected to your network.
Save Layout
Save customized pushbutton layouts for the different environments in which you use
your Videohub.
Highlighted Pushbuttons
denote paired connections
Use TAKE
Sources Area Search
Scrollbars indicate
not all pushbuttons
are visible
Destinations
Area Search
List View
Reveal Source Pushbutton View
Blackmagic Videohub Control 30 30
