FLAT
Valid for Standard and Globetrotter XL cabins
6
Then connect the pump tube (X) to the tank and
secure the tank (choosing the best position of
the filling cap, left or right, in order to facilitate
filling) with the supports supplied. The support
with the ridge is used when mounting the tank
with the filling cap (Y) to the left side.
6
7
Assemble the filter in the tube with a stud,
introduce in the cap and connect to a Ø18 x Ø12
(A) return tube.
X
A
47
EN
®
6
Y
A
