OPERATOR'S MANUAL
16 / NORMAL OPERATION
Figure 13
Grain Selection Menus
Corn
Product
Average
Remain
on
product
for 3
seconds
Soybeans
050208N
K1 = 1783
K2 = 7205
K3 = 1488
K4 = 8155
Bias
Soybeans
TWBias = x.x
MBias = x.x

GRAIN SAMPLE TESTING

To begin Grain Test:
1. Ensure Loader is removed from the top of the unit.
2. With the product name selected at the top of the display,
press the Enter button.
3. The cell must be empty, upright, and still to perform an empty
cell test. When the Empty Cell menu displays, press the
Enter button.
IMPORTANT: The empty cell reference measurement is used
for all product testing until the unit is powered
off. It is critical that the cell be clean and
completely empty when the unit is on. Keep
the measurement cell opening clear of hands
or other objects during this period.
4. After the empty cell test completes, the Fill Cell menu
displays.
5. With the slide closed, scoop or pour grain into the Loader
over the minimum fill line as shown in
6. Place the Loader on top of the unit.
Product
Corn
Soybeans
Calibration
1/3
Constants
Soybeans
K5 = 2455
K6 = 2074
K7 = 2606
K8 = 9916
K9 = 1087
2/3
3/3
Soybeans
Home
Menu
Product
Average
(Figure 14).
mini GAC
11001-1464 Rev C
®
