Test/ Disable Options

The test and disablement options available are tabulated below.
TEST or DISABLE status change method for single zones is described.
Follow the same procedure to change status of other setup options.
ALL ZONES SINGLE ZONE FIRE O/P
TEST DISABLE TEST DISABLE
OPTION
1
2
3
4
5
6
7
* Only selectable if a 4-way sounder PCB is fitted and configured for SST operation.
1
2
3
3
4
able ALL zon
4
SOUNDER FAULT O/P
DISABLE DISABLE DISABLE
5
1 Insert and turn key
SST
DISABLE *
90° clockwise to enable
access Level 2 controls.
2 To step through setup
options 1-7 , press
illuminate
Flashing LED indicates
current selection, e.g.
Zone 1.
3 Press
NORMAL,
DISABLEMENT status -
confirmed by
indication change. Also use
as a 'special select'
function - see below.
4 Repeat steps 2 & 3 as
required to make other
changes.
5 Turn key
clockwise: returns you to
access Level 1 and saves
all changes. The
is lit steadily.
6 To cancel status change,
repeat steps 1 to 5 to
extinguish the
'Special Select' Function
With a number of active
(fire or fault) zones, repeat-
edly press to disable, test
or deselect all active inputs
in one control selection -
selected state confirmed by
DISABLEMENT or TEST LED
lit and rapid flashing of the
active zone LEDs.
