12

TROUBLESHOOTING

Problem
The display does
not become lit
StoP appears on
the display
The letter A
appears blinking on
the display
The cups break
Blade breakage
The balls break
Oranges are not
thoroughly
squeezed
Oranges dash out
from the paddle
The machine does
not stop with cups
in vertical position.
For any queries or request for spare parts, please state the model and identification
number of your machine (Fig. 5).
16
Cause and/or solution
Lack of electrical current.
Fuse burnt out. (Fig. 11-1)
Power cable improperly connected.
Turn on the power switch. Fig. 6
Humidity in electronic plate. Provide dry heat to the plate.
Cover not properly in place. (Figs. 8 & 9)
Tray that holds squeezers out of place. (Fig.10)
Check to see if frozen oranges are being squeezed.
Check if peelings have piled up on the tray that holds squeezers.
Check to see if balls have been left un-tightened.
Check to see if peelings are left stuck to the inside of cups.
To unblock the machine, use an Allen key of 5mm which you will find at
the right side of the grid. Introduce it in the right side lateral hole
(Fig.21) and, with the machine switched off, turn the key clockwise till
cups are up and the machine is unblocked.
LOOK OUT: before switching the machine, make sure that the key is
out of the anchorage.
Nuts on the cups are improperly tightened.
Excess of washers under the balls.
The balls on the tray that holds squeezers are loose.
The blade is not properly positioned.
Do not place Dark-coloured cups with large Bright-coloured balls (Ø80).
Oranges are either too small or too large for the cups.
The blade has been placed over its shaft.
The Balls are loose.
The nuts on the cups are improperly tightened.
More than two washers have been placed under each ball.
Washers are missing under balls.
Orange peels are too thin; place a maximum of one washer under balls.
The paddle shaft is too dry; proceed to grease it. (Fig. 18)
The process that must follow to modify the STOP point
from the electronic plate is the following one:
- To disconnect the machine by means of the back switch.
- To connect again simultaneously that STOP is pressed. four numbers
will appear in the screen.
With the four numbers in screen ( it appears 3 seconds) press
button ON. A number from the 0 to the 9 will appear on the left of the
screen. The shown number corresponds to tenth of second of delay in
not operating of the machine, for which and if you need to stop the
machine you have to select an inferior number than the shown one in
screen. In order to change this number, press ON (when the screen
shows the number to the left) number will change. Enabling electronic to
memorize this number, you will have to wait 5 seconds (the screen will
show then a number in the central position, corresponding to the number
of oranges selected).
Verify that the unemployment point is the correct one. If it's not, repeat
the process with another value.
