Movement EDGE ABDOMINAL Manual De Montaje página 68

ASSEMBLY
STEP 16 - ASSEMBLY THE COUNTER (OPTIONAL)
34
Internal flat head hex screw
M6X16
35
Internal Hex Cyl. Head screw
M6X20
Allen n°8
Allen n°5
1
2x
1x
2
3
Display
4
1 2
Vista traseira
do display
3
1 2 3
ENCODER
5
34
6
Pilhas
32
8
OBS: Place the battery door inside the
with the velcro before mount the fairing
in the tower
34
35
