M O TI ON C M D - 02 TUB U L AR M O TO R
16
Reset favourite position
Move the blind to a desired favourite position.
16.1
Press the program button on the motor to activate
16.2
Centre
program mode. The blind starts stepping.
Hold the centre button to save this favourite position. The blind
16.3
shortly stops stepping, indicating the favourite position has
been saved succesfully.
Press the program button on the motor to deactivate
16.4
program mode. The blind stops stepping.
17
Reset the blind
It is possible to only delete end limits or to do a factory reset.
Factory reset will delete the end limits and remove the connection to any paired remote.
Shortly press the program button on the motor to activate program mode.
17.1
Delete end limits: to delete the end limits of the blind, hold the program button
until the blind stops stepping for the first time, and keep holding the button until
the blind stops stepping for the second time. (approximately 10 seconds)
Factory reset: to reset the blind to factory defaults, hold the button for at least 20 seconds. The blind will
stop stepping twice. After the second stop, the blind will give one extra step to confirm factory reset.
M O T I O N C MD -02 T U B U LA R MO TO R
18
Recharge the battery
Use a micro USB cable to charge the motor.
LED light flashes
LED light flashes
red during operation;
Charge the battery
battery is charging
Frequently Asked Questions
Problem
Cause
Motor is not activated
Motor battery is empty.
Remote battery is empty. (LEDS of remote
are flashing rapidly.)
Remote battery is inserted incorrectly.
Blind does not work.
Radio-frequency interference
The distance from the remote to
the motor is too far.
The remote is not connected to
the blind.
Motor LED flashes red.
The battery of the motor is empty.
Blind is not charging.
Charger is not plugged in or does not work.
Blind moves in small steps.
No end limits are programmed.
Favourite position can not
No end limits are programmed.
be programmed.
Blind lowers too far.
End limits are programmed incorrectly.
Blind moves in the opposite
The rotational direction has been
direction
set incorrectly.
The blind keeps moving up and
The blind is in program mode.
down.
LED light constantly
green;
green;
battery is fully charged
Solution
Activate the motor. See step 1.
Charge the motor. See step 18.
Replace the battery in the remote.
See the manual of the remote.
Replace the battery in the remote.
See the manual of the remote.
Make sure that the antenna of the motor is
out of the way of metal objects.
Move closer to the motor.
Pair the remote with the motor.
See step 6.
Charge the motor. See step 19.
Try a different charger or make sure the
charger is plugged in the outlet.
Program end limits. See step 8 - 11.
Program end limits . See step 8 - 11.
Reprogram end limits. See step 8 - 11.
Change the rotational direction.
See step 7
Press the program button on the motor
to exit program mode.
