en

Mechanical installation

™
● ISA100 Wireless : Activate using PolySoft.
The blue LED flashes.
4.2.3 PerformingBluetooth
Prerequisite:
®
– Bluetooth interface is activated.
● If the factory Bluetooth
®
Bluetooth pairing is automatic.
After successful Bluetooth
continuously.
Gas detector and Windows mobile device with PolySoft
are connected.
If necessary, use PolySoft to assign an individual Bluetooth
pairing PIN.
NOTICE
► Keep the individual Bluetooth
4.2.4 Connecting the ISA100 Wireless
interface
● Connect the Windows mobile device with the respective
management station of the ISA100 Wireless
The configuration is done with PolySoft.
5 Mechanical installation
WARNING
Risk of explosion!
In explosion-hazard areas, electrostatic discharge may cause
a spark to ignite on the antenna.
► Do not install the antenna in explosion-hazard areas
subject to intense electrostatic charging, for example, due
to fast moving particles or pneumatic transport of
powders.
WARNING
Risk of explosion!
In explosion-hazard areas, electrostatic discharge may cause
a spark to ignite on the housing and sensing head.
► Do not install the gas detector in dust explosion-hazard
areas subject to intense electrostatic charging, for
example, due to fast moving particles or pneumatic
transport of powders.
5.1 Installing the gas detector -
installation without mounting
accessories
The gas detector is installed vertically on a flat surface.
For installation with mounting accessories, see
corresponding assembly instructions.
®
pairing
®
pairing PIN "000000" is used,
®
pairing, the blue LED lights up
®
pairing PIN in a safe place.
™
™
network.
Prerequisites:
– A suitable installation location is selected (see "Safety
information", section "Mechanical installation", page 21).
CAUTION
Risk of explosion!
The gas detector is not tested in environments with increased
oxygen content (> 21 % O
► Do not use the gas detector in environments with
increased oxygen content.
Install the gas detector:
● Install the gas detector using the drilling template (see
"Drilling template" appendix) and M6 (1/4") hexagon
®
socket head cap screws.
5.2

Installing the antenna

1. Remove the cover cap from the antenna connector
(Fig. A 3).
2. Screw the antenna into the connector and tighten it by
hand.
5.3

Installing the remote antenna

1. Remove the cover cap from the antenna connector
(Fig. A 3).
2. Screw the antenna cable into the connector and tighten it
by hand.
3. Select an installation location where a perfect signal
transmission is ensured. The antenna must point up
vertically.
4. Attach the mounting bracket at the installation location of
the remote antenna.
5. Lay the antenna cable.
6. Screw the remote antenna in at the end of the antenna
cable and tighten it by hand.
5.4

Installing the sensor

If the gas detector is already switched on and an existing
sensor is changed, see "Changing the sensor", page 32.
For specific information, refer to the sensor data sheet.
Prerequisites:
– The gas detector is installed.
Install the sensor:
1. Loosen the set screw (Fig. B 2).
2. Unscrew the bayonet ring (Fig. B 3).
3. Remove the dummy disk.
4. Insert the sensor (Fig. B 4) into the opening so that the
Dräger logo is aligned with the marking on the housing
(Fig. B 5).
5. Secure the sensor with the bayonet ring.
6. Tighten the set screw. Required for installation in Zone 22.
Dräger Polytron 6100 EC WL, Dräger Polytron Repeater ISA
).
