SYSTEM CABLE SC5 (Optional, available separately)
System cable SC5 connects the handsfree unit with the power supply, the ignition system, the mute socket of the car radio
and the car speakers. It includes the mute box (MB2) with relay components and a cable with ISO standard sockets. Please
see the chapter "Installation" where the connection diagram is shown.

INSTALLATION

INSTALLATION
Fuse
SC2
MB2
SC5
Fuses
M1
RC1 Location 2
RC1 Location 1
GB - 4
Fuse
SC3
ISO connectors
SM3
