Recline Adjustment - Nuna todl next Manual De Instrucciones

Recline Adjustment

1
- Squeeze the recline adjustment button to adjust the enhanced child
restraint to the proper position. (19)
2
- Both rear facing mode and forward facing mode have 5 recline positions,
the recline angles are shown as. (20)
Rearward Facing Mode
(Child height 40cm-105cm/ Child weight ≤19kg)
Please install the enhanced child restraint on the rear vehicle seat, and
then place the child in the enhanced child restraint.
1
- Push the enhanced child restraint down onto the base (21). If the
enhanced child restraint is secure, the enhanced child restraint indicator
will show green. (22)
2
- To release the enhanced child restraint, first take the child out of the
child restraint. Squeeze the child restraint release button (23)-1, then lift
the child restraint up (23)-2.
The enhanced child restraint can ONLY be installed and released when in
rearward facing mode.
3
- Press and hold the ISOFIX adjustment button and push the enhanced
child restraint system back until it comes in contact with the vehicle
seatback. (24)
4
- Press and hold the rotation button to rotate for easier side loading/
unloading of the child, then rotate the seat to the rear facing position.
(25)
Press the rotation button on either side to rotate the enhanced child
restraint.
5
- Press the harness adjustment button while pulling the shoulder
harnesses to the desired length (Pull from below the fixed shoulder pads
to lengthen). (26)
6
- Unlock the buckle of the harnesses by pressing the red button. (27)
7
- Place the buckle tongues against the magnetic area on the outer side of
the enhanced child restraint so that the tongues are held in place. (28)
11 TODL next instruction
Use Infant Insert
We recommend using
the full infant insert
while the baby is under
60cm and ≤13kg. It can be used
until they outgrow the insert.
The infant insert increases
side impact protection.
8
- Place the child into the enhanced child restraint and pass both arms
through the harnesses.
9
- Engage the buckle. Please refer to (29).
10
- Rotate the enhanced child restraint to rearward facing. The enhanced
child restraint indicator will show green. (30)
11
- Pull down the adjustment webbing and adjust it to the proper length to
make sure your child is properly secured. (31)
Always keep child secured in harness and properly tightened by
removing any slack.
Remove the head support
portion of the infant insert
when the child's
head no longer fits
comfortably.
Remove the body
portion of the infant
insert when the infant's
shoulders no longer fit
comfortably.
Remove the infant insert
1
cushion by detaching the
snaps to allow more space
when the infant does not
fit comfortably. The
cushion can be used
2
separately without being
attached to the insert to
bolster the infant's back
for more comfort.
TODL next instruction 12
