Setup

The Charge Pockets

MX3 Multi-Charger Plus User's Guide
•
Ensure that the location you choose for the charger/analyzer is well ventilated.
•
Place the charger/analyzer on a horizontal, hard surface.
•
Plug the power cord into a properly grounded outlet.
•
On initial power-up, all 5 pocket LEDs will light yellow for a few seconds.

Figure 3 Charge Pocket Components

1. Battery Charging Pocket
2. Retaining Pins
3. Battery Charger Contacts
4. LED Indicator
