20
Ready
The Ready indicator is displayed at the end of the charge only or the analyze process. After the
charge only process, the screen indicates the battery pack's voltage.
The LCD indicates:
After the analyze process, the screen displays the battery pack's voltage and capacity.
The LCD indicates:
MX3 Multi-Charger Plus User's Guide
READY
Figure 12 LCD Screen, Charge Only, Battery Ready
•
The charging is complete and the battery is ready for use (READY).
•
The battery voltage after charge (12.2VDC). This reading can vary between
10.2VDC and 12.6VDC.
ANALYZE
READY
Figure 13 LCD Screen, Analyze, Battery Ready
•
The battery was under analysis (ANALYZE).
•
The process is complete and the battery is ready for use (READY).
•
The battery capacity as it is measured during the analysis (1400mAh).
•
The battery voltage after charge (12.2VDC). This can vary from 12.0VDC to
12.7VDC.
Progress Monitors
12.2
V
1400
mAh
12.2
V
E-EQ-MX3MCPLUS-F-ARC
