18
Analyze – Discharge
The next step in the analysis is the automatic discharging of the battery pack. The discharge
requires 1.5 to 4 hours.
The LCD indicates:
For information on battery capacity, please refer to "Battery Capacity" later in this manual.
MX3 Multi-Charger Plus User's Guide
DISCHARGE
1
ANALYZE

Figure 10 LCD Screen, Analyze, Discharge

The battery is discharging (DISCHARGE).
This is the first (and only) discharge cycle (1).
The battery is under analysis (ANALYZE).
The battery capacity as measured during the discharge (1120mAh).
The battery voltage under discharge (10.2VDC). This can vary from 9.0VDC to
12.7VDC.
Progress Monitors
1120
mAh
10.2
V
E-EQ-MX3MCPLUS-F-ARC
